Wet Film Thickness Gauge

TQC Sheen brand

Description

Wet Film Thickness Gauge Stainless Steel

TQC Wet Film Thickness Gauge WG is a hexagonal or octagonal precision measuring comb, that it made by a heavy duty stainless steel. The high-grade stainless steel will not be affected by acid also base elements, and also several models are available for the different applications.

Wet Film Thickness Gauges are designed to measure the thickness of wet coatings immediately after they have been applied to a substrate. The gauge has a series of notches cut into its sides like the teeth on a comb. The wet film thickness of coatings including paints, resins, lacquers, varnishes and gels an so on can be measured.

Hexagonal/Octagonal precision measuring comb made of heavy stainless steel. The high-grade stainless steel will not be affected by acid and also base elements either.

Standards: ISO 2808, Available in both Microns and also Mils scale.

4 models available for several different applications:

Wet Film Thickness Gauge SP4000 – WG I

Wet Film thickness Gauge TQC Stainless Steel



20-370 μm in 24 steps (6×4) for decorative paints and also primers.

  • Side=1: 20, 30 40,50
  • Side=2: 60, 70, 80, 90
  • Side=3: 100, 110, 120, 130
  • Side=4: 150, 170, 190, 210
  • Side=5: 230, 250, 270, 290
  • Side=6: 310, 330, 350, and finally 370





Wet Film Thickness Gauge SP4010 – WG II

TQC Wet Film Thickness Gauge Stainless Steel



25-2000 μm in 36 steps (6×6) With edge grinding check (2mm) for protective coatings and also high solids.

  • S1: 25, 50, 75, 100, 125, 150
  • S2: 175, 200, 225, 250, 275, 300
  • S3: 350, 400, 450, 500, 550, 600
  • S4: 650, 700, 750, 800, 850, 900
  • S5: 950, 1000, 1100, 1200, 1300, 1400
  • S6: 1500, 1600, 1700, 1800, 1900, and the last 2000





Wet Fil Thickness Gauge SP4020 – WG III

TQC WFT Gauge

50-10000 μm in 71 steps (8×9) Scale division: 0-900:50μm, 900-5500:100μm, 5500-9000:500μm for extremely thick films such as floor coatings, fillers, fire proofing, plaster, adhesives etc.

  • side-1: 50, 100, 150, 200, 250, 300, 350, 400, 450
  • side-2: 500, 550, 600, 650, 700, 750, 800, 850, 900
  • side-3: 1000, 1100, 1200, 1300, 1400, 1500, 1600, 1700, 1800,
  • side-4: 1900, 2000, 2100, 2200, 2300, 2400, 2500, 2600, 2700
  • side-5: 2800, 2900, 3000, 3100, 3200, 3300, 3400, 3500, 3600
  • side-6: 3700, 3800, 3900, 4000, 4100, 4200, 4300, 4400, 4500
  • side-7: 4600, 4700, 4800, 4900, 5000, 5100, 5200, 5300, 5400
  • side-8: 5500, 6000, 6500, 7000, 7500, 8000, 8500, 9000, and the last is 10000





SP4050 – WG II

Wet Film Thickness

WFT Stainless Steel

1-80 mils in 36 steps (6×6) With edge grinding check (2mm) for protective coatings and also high solids.

  • S-1: 1, 2, 3, 4, 5, 6
  • S-2: 7, 8, 9, 10, 12, 14
  • S-3: 16, 18, 20, 22, 24, 26
  • S-4: 28, 30, 32, 34, 36, 38
  • S-5: 40, 42, 44, 46, 48, 50
  • S-6: 55, 60, 65, 70, 75, and finally 80

Use

  • Firstly Place the gauge at a 90° angle to the coated substrate
  • Secondly Make sure the gauge is in firm contact with the substrate.
  • After that Remove the gauge in a straight line up.
  • Finally Assess the teeth of the gauge. The wet film thickness lies between the largest tooth that is wet and the smallest tooth that is not wet.

Wet Film Thickness Aluminum Comb & Octagonal

For measuring wet film thickness of paints, enamels, lacquers, adhesives & many other wet coatings that are sprayed, dipped or brushed on a smooth surface.
Meets ISo 2808 and ASTM D4414 “Standard Practice for Measurement of Wet Film Thickness of Organic Coatings by Notched Gauges” Standard used is traceable to NIST- All Aluminum Comb – Size: 2-1/4 ” x 3-1/4″ x .034″. Rectangular measurement comb with the range of 25 to 2000 microns with top quality. Also available special printing or logos with large order quantity.

Wet film thcikness Aluminum

For more detail and related products information please contact us.
