What is CROSS CUT ADHESION TEST ?
Cross cut adhesion test methods cover procedures for assessing the adhesion of coating films to metallic substrates by applying and also removing pressure-sensitive tape over cuts made in the film. In order to perform this procedure, one ought to have the required tools: the crosscut kit, magnifier and a table chart. The kit consists of parallel knives used to cut through the dry paint.
The first test requires to make a lattice pattern in the film to the substrate by producing a series of parallel cuts, and then cross-angled to each other to produce 25–100 squares of the same dimensions. The second, short treatment is done on the ruled area by brushing in a diagonal direction; pressure-sensitive tapes can also be used for hard substrates. Finally, the grid area is examine and evaluated by a magnifier and also the standard table chart to determine the adhesion rate of the coating or paint.
The coating removal is specially use to determine the rate of adhesion. The variance of the adhesion of coatings comes as a result of the surface treatment or the nature of the substrate. A crosscut adhesion test is done on different substrates provided there exists a film of coating.
Firstly is TQC CROSS CUT ADHESION TEST KIT CC1000
The TQC Cross Cut Adhesion Test KIT CC1000 is a destructive method use to test the adhesion of dry coats of paint on their substrate. With two series of parallel cuts cross angled to each other to obtain a pattern of 25 or 100 similar squares. Then the ruled area is evaluated by using a table chart after a short treatment with a stiff brush, or adhesive tape for hard substrates.
The round cutting knife of the TQC CC1000 Kit has eight cutting edges, that can be changes easily only by rotating the knife. The self positioning knife bracket will ensures equal pressure on the cutting knife.
Each TQC Cross Cut Adhesion Test KIT CC1000 contains a grip with cutter, a brush, an illuminated loupe and also a roll of adhesive tape acc. EN ISO 2409.
Secondly is TQC Cross Cut Adhesion Test KIT CC2000
TQC CC2000 Test KIT is use to test the adhesion of dry coats of paint on their substrate by means of a series of cuts through the coating.
Two series of parallel cuts cross angle to each other to obtain a pattern of 25 or 100 similar squares. The ruled area is evaluable by using a table chart after a short treatment with a stiff brush, or adhesive tape for hard substrates.
Because the cutting knife is very easy to exchange, and user friendly that why there is no use of extra tools. The self positioning knife bracket will ensures equal pressure on the cutting knife.
Each KIT CC2000 contains a grip with cutter, a brush, an illuminated loupe and also a roll of adhesive tape acc. ISO 2409.
Application area’s : Coating/Paint Industry, Galvanise, Automotive, Laboratory, Painters, Shipping Industry, Steel Protection, and also Wood.
Features ·
- Self-adjusting knife-holder for ensures equal pressure on the cutting knife
- Ergonomically shaped handle
- Easy to change cutting knife, so no extra key needed
- Wide range of knife sizes available for different coating thicknesses substrates and also according to different
Standard delivery Cross of Cut Adhesion Tester acc. to DIN-ISO, 6 teeth
SP1690 TQC CCA test kit CC2000, incl. blade 1mm
SP1691 TQC CCA test kit CC2000, incl. blade 2 mm
SP1692 TQC CCA test kit CC2000, incl. blade 3 mm.
Standard Delivery of Cross cut Adhesion Tester acc. To ASTM, 11 teeth
SP1699 TQC CCA test kit CC2000, include blade 1 mm.
SP1700 TQC CCA test kit CC2000, incl. blade 1,5 mm.
The test kit contains a soft grip handle, a hardened steel cutter (type may vary, see above), a nylon.
Available optional spare knife of CCA Test Kit according to your job requirement.
Finally is TQC CC3000 TEST KIT
Through its extensive adjustment possibilities, this version is ideal if the test is perform by constantly changing persons.
The CC3000 test kit is use to test the adhesion of dry coats of paint on their substrate. By means of a series of cuts through the coating. Come with two series of parallel cuts cross angled to each other to obtain a pattern of 25 or 100 similar squares. The ruled area is evaluable by using a table chart. After a short treatment with a stiff brush, or adhesive tape for hard substrates.
FEATURES
1. Firstly The blade holder is kept at a set distance from the surface, with the aid of two wheels (ball bearings) to ensure reproducible test results guaranteed. The depth of the TQC CC3000 kit is adjustable to measure coatings from 25 until 250 µm thick
2. Secondly Ergonomically shaped handle
3. Than Easy to change cutting knife
4. Finally Wide range of knife sizes available for different coating thicknesses and substrates and according to different standards.
Each TQC Cross Cut Adhesion Test KIT CC3000 contains a grip with cutter, a brush, an illuminated loupe and a also roll of adhesive tape acc. EN ISO 2409.
MASTER PAINT PLATE
Versatile measuring tool with common tests for paints and coatings. TQC Master Paint Plate is a stainless steel measuring tool, that features : a 1, 1.5, 2 and also 3 mm. The cross-cut-adhesion-test according NEN-EN-ISO 2409:2003 and also ASTM D 3359 (X-cut) Andreas cross.
Additional tools
- Wet film thickness gauge ranging from 50 microns until 160 microns.
- On the corners there is an edge grind checker for correct roundness of edges.
- At the bottom is a wet film applicator ranging from 0 until 180 µm.
- The top edge provides a leveling test, an indication of the viscosity of the coating.
- Delivery includes cutting tool and also tape.
The TQC adhesion test tape is manufacture according to ISO 2409:2003 and ISO 2409:1999, can be orders separately as well.
This product manufactured according to standards NEN-EN-ISO-2409, ASTM D3359
